VOLKSWAGEN ADAS CALIBRATION

Scanning all ADAS modules for stored fault codes via ODIS-Service.

Checking the windshield camera bracket for cracks, displacement, or moisture.

Inspecting the ACC radar housing behind the VW badge for impact or rotational shift.

Setting tyre pressures to VW-specified kerb weight values for a consistent ride height.

Zeroing the steering angle sensor and confirming the vehicle is on a level surface.

The Volkswagen is positioned inside a purpose-configured indoor bay meeting ODIS dimensional guidelines.

VW Group-specified target boards are mounted at certified heights and distances from the front camera lens.

ODIS connects through the OBD-II port and runs the automated camera alignment and verification sequence.

The software resets the front camera's horizontal and vertical reference angles to VW factory tolerances.

Following a static setup, a technician drives the vehicle on well-marked roads between 40 and 100 km/h.

ODIS monitors real-time sensor outputs: lane edge recognition, radar object acquisition, and distance accuracy.

Confirms that Travel Assist, Lane Assist steering response, and Adaptive Cruise Control all meet VW's operational thresholds.

Front-Facing Camera (Upper Windshield)

Target board alignment corrects the camera's pitch and yaw back to Volkswagen's longitudinal vehicle axis.

Restores precise Traffic Sign Recognition, Pedestrian Detection, and Lane Assist lane-edge sensitivity.

Performance is confirmed during the post-static dynamic drive with live ODIS data monitoring.

ACC Long-Range Radar (Front Grille / Badge Area)

The radar beam is re-aimed using a precision squaring frame to run true and level with the road ahead.

Correct alignment is essential for Travel Assist to track the lead vehicle at the right distance.

Recalibrated thresholds ensure Front Assist emergency intervention happens at precisely the right moment.

Blind Spot Sensor Array (Rear Bumper Corners)

Corner-mounted radar modules are calibrated to cover the correct adjacent-lane detection zones.

Rear Traffic Alert triggering distance and sensitivity verified for safe low-speed reversing across traffic.

Parking Cameras – Area View System

Camera stitch points realigned for a continuous, undistorted overhead parking perspective.

Park Assist trajectory guidance lines confirmed to accurately reflect the Volkswagen's true turning path.

A full ODIS re-scan across every control module to confirm zero residual fault codes remain active.

A live road verification run to validate Travel Assist following behaviour and Lane Assist steering response.

Complete digital logging of calibration results, ODIS session data, and technician certification details.

Issuing of a formal safety calibration compliance certificate for the vehicle owner's insurance and log book records.
