NISSAN ADAS CALIBRATION

Scanning all ADAS modules using Nissan-approved diagnostic tools (like CONSULT-III Plus).

Checking for any existing fault codes or Nissan Intelligent Mobility system errors.

Inspecting cameras, radar sensors, and ultrasonic sensors for physical damage.

Verifying tyre pressure and wheel alignment are within Nissan’s factory specifications.

Confirming the vehicle is on a level surface while having a full fuel tank.

While the vehicle is parked on a perfectly level surface,

Specific Nissan OEM-approved calibration targets and boards are placed at precise distances.

Then, Nissan's diagnostic software is connected to the vehicle’s OBD port.

By using these targets and the software, we realign the Nissan 360 camera and radar arrays.

The vehicle is driven on a road at specific speeds (typically 40–100 km/h).

When clear lane markings appear, the camera then ‘reads’ the environment.

The software self-calibrates while driving by monitoring:

Lane markings for Intelligent Lane Intervention.

Vehicle distances for Intelligent Cruise Control.

Surrounding environment for Blind Spot Warning.

Safety Shield 360 Camera (Windscreen-Mounted)

Calibration target placed at a measured distance in front of the Nissan.

CONSULT-III Plus software initiates the camera alignment routine.

Camera adjusts its field of view to factory specifications for Nissan Intelligent Mobility accuracy.

Dynamic drive test confirms lane detection and traffic sign recognition.

Front Radar Sensor (Behind Nissan Badge/Bumper)

Vehicle centered on an alignment ramp or level floor.

Nissan-specific radar alignment target placed directly ahead.

The diagnostic tool runs a radar beam alignment to ensure long-range accuracy.

Verifies detection range for Forward Collision Warning and Intelligent Cruise Control.

Intelligent Around View Monitor (Nissan 360)

Specialized floor mats/targets are placed around the entire perimeter of the vehicle.

Individual cameras in the grille, mirrors, and tailgate are digitally "stitched."

Ensures a seamless, distortion-free overhead view for safe parking.

Blind Spot & Rear Cross Traffic Radar

Static targets are placed at measured angles beside the rear quarter panels.

Sensors calibrated for accurate detection zones within the Nissan Safety Shield parameters.

Verified to prevent false positives from roadside objects.

A full rescan for all Nissan Intelligent Mobility modules to confirm no fault codes remain.

Road test to verify system performance of the Nissan 360 sensor suite in the real world.

Comprehensive documentation of calibration results for insurance and compliance records.

Issuing of a post-calibration Nissan-compliant safety certificate.
